Junsi iCharger DX12 DC Battery Charger features:
The Junsi iCharger DX12 is a cutting-edge charging solution designed to meet the demands of hobbyists and professionals alike. With advanced synchronous buck-boost DC/DC converter technology, this charger delivers high-power and high-current performance for efficient battery charging. Let’s explore its impressive features:
Maximum Charge Power Capacity: The DX12 boasts a maximum charge power capacity of up to 1700W, ensuring rapid and effective charging. It supports a wide range of battery types, including:
- LiPo
- LiFe
- NiMH
- NiCd
- And more!
Dual-Channel Design:
- Simultaneously charge two batteries with the dual-channel design (up to 30A per channel).
- Versatile and adaptable for various applications.
Informative LCD Screen: The 2.8″ IPS LCD screen provides real-time monitoring of charging parameters:
- Current
- Voltage
- Power
- Capacity
- Internal resistance
- Temperature
Safety Features:
- Digital-Power Mode: Enhanced protection with features like over-current and over-voltage protection.
- Intelligent Fan Control: Based on internal temperature sensing, it ensures efficient cooling during charging.
Type-C Power Delivery (PD) Port:
- Conveniently charge your mobile devices using the Type-C PD port.
Balancing Technology:
- Advanced balancing technology with internal resistance correction ensures optimal battery health.
Multi-Discharge Options:
- Choose from various discharge modes, including regenerative discharge.
User-Friendly Interface:
- Easily manage your charging operations with the user-friendly interface.
- Import/export data and upgrade as needed.
Whether you’re an RC enthusiast, drone pilot, or hobbyist, the iCharger DX12 offers unmatched performance and reliability—a must-have for precision and efficiency in battery management!
Specifications:
- Dimensions: 4.4×5.06×1.6in. (111.5×128.5x40mm)
- Weight: 17.64oz (500g)
- Maximum Charge Power Capacity: 1700W (1200W per channel)
- Maximum Charge/Discharge Current: 50A (30A per channel)
- Maximum Discharge Power Capacity: 80W (Channel 50Wx2)
- Maximum Regenerative Discharge Power Capacity: 1700W (Channel 1200Wx2)
- Maximum Extra Discharge Power Capacity: 3000W (Channel 1500W @ 50V/30A)
- Maximum Current Drain for Balancing: 4A (Channel 2Ax2)
- Type-C PD Port: 5V/3A, 9V/2A, 12V/1.5A
- Support Battery Type: LiPo, Lilo, LiFe, LiVH, LTO, NiZn, NiMH, NiCd, Pb
- Input Voltage Range: 11—53VDC
- Maximum Input Current Limit: 65A (Channel 45A)
- Maximum Current Drain for Balancing: 2A x2 (4A Bridged)
Includes:
- (1) iCharger DX12 Dual DC Battery Charger
- Balance boards and cables
- Power cables
- Instruction manual
